Another first: Curiosity rover flexes its arm on Mars

NASA's Mars rover Curiosity flexed its long robotic arm for the first time on the Red Planet on Monday, passing a critical health check with flying colors, mission managers say.
Image: Robotic arm unleashed
A mosaic of low-resolution images from the Curiosity rover's navigation camera system shows the rover's robotic arm extended for the first time on Monday.NASA / JPL-Caltech
/ Source:

NASA's Curiosity rover flexed its long robotic arm for the first time on Mars on Monday, passing a critical health check with flying colors, mission managers say.

The rover unfolded the robotic arm and performed an intricate series of test maneuvers to make sure the 7-foot-long (2.1-meter) appendage is in good working order. Curiosity's robotic arm has five joints and is tipped with sophisticated instruments to get up close and personal with Mars.

Monday's Martian workout flexed all five joints on the robotic arm to extend it out in front of Curiosity, and then fold it back into its travel position ahead of the rover's first drive, which is expected to occur in the next few days.

"It worked just as we planned," Louse Jandura, Curiosity's sample system chief engineer at NASA's Jet Propulsion Laboratory in Pasadena, Calif., said in a statement. "From telemetry and from the images received this morning, we can confirm that the arm went to the positions we commanded it to go to."

Curiosity's robotic arm is one of the rover's most powerful tool kits. At the end of the arm is a bulky 66-pound (30-kilogram) turret that is nearly 2 feet wide (60 centimeters). [11 Amazing Facts About the Curiosity Rover]

The arm's turret contains a drill that can bore an inch (2.5 centimeters) deep into Martian rocks, a scoop and other gear for collecting samples, a camera for microscopic analyses, and a spectrometer to determine the composition of rocket and surface targets.

"We'll start using our sampling system in the weeks ahead, and we're getting ready to try our first drive later this week," said Richard Cook, NASA's deputy project manager for the Curiosity mission.

But more robotic arm tests are needed before Curiosity can begin using the appendage to study Mars. Mission managers said the arm must pass several calibration checks to make sure it is working properly.

"We have had to sit tight for the first two weeks since landing, while other parts of the rover were checked out, so to see the arm extended in these images is a huge moment for us," said Matt Robinson, NASA's lead engineer for the robotic arm testing. "The arm is how we are going to get samples into the laboratory instruments and how we place other instruments onto surface targets."

Monday's arm checkout came one day after Curiosity shot a nearby rock with a laser built into its mast to make sure the tool worked. That tool is part of Curiosity's Chemistry and Camera (or ChemCam) instrument that determines the composition of targets by zapping them with laser beam and then analyzing the light from the resulting sparks. The laser system, like the robotic arm, worked as expected.

The $2.5 billion Mars rover Curiosity touched down on the Red Planet on Aug. 5 and is expected to spend at least two years exploring its Gale Crater landing site. The rover is designed to determine if the region could have ever supported microbial life.
